Flake Ice Plant

Click to enlarge

ABOUT

Lintec Flake Ice Plant for concrete cooling can be used in extreme hot climate regions to produce quality concrete at desired temperatures for special requirements. The Ice Plant can be used in projects such as dam projects, airport projects and those that require high concrete strengths.

Description

FEATURES & BENEFITS

  • Containerised structures
  • Low shipping & transportation costs
  • Fast set-up and dismantling for relocation
  • High performance to cool down concrete even in extreme hot climate areas
  • Easy maintenance
  • Energy-efficient and water savings
  • Fully automatic

For 35 °C to 45 °C Ambient Temperature

Wet Bulb Temp.: 25 °C

Water Inlet Temp.: ≤ 10 °C

Refrigerant: R404A (Not Included)

Power Supply: 3 Phase, 380V to 415V, 50 Hz

(Special voltage models available upon request).

SPECIFICATIONS

Flake Ice Plant Technical Specifications

Model SIM15 SIM20 SIM30 SIM40
Daily Ice Capacity
15 tons/day
20 tons/day
30 tons/day
40 tons/day
Necessary Refrigeration
75 kW
100 kW
150 kW
200 kW
Water Consumption
226.9 litres/hour
277.3 litres/hour
395.1 litres/hour
528.5 litres/hour
Power Installation
90.3 kW
91.55 kW
139.2 kW
173.2 kW
Container Size
20 ft.
40 ft.
40 ft.
40 ft.

All specifications are subjected to changes without prior notice.

Automatic Ice Storage System

Model Capacity Type
IST1
20 tons
40 feet Container
IST2
40 tons
Assembly at site

All specifications are subjected to changes without prior notice.

Automatic iced storage systems are equipped with Polyurethane insulation materials and temperature controller and sensors, horizontal screw conveyor, ice raking device & hoist device, ice deflecting device, and automatic control & monitoring systems.
